Spesifikasi:

Radio specification
• AP type: Indoor, tri radio, dual 5 GHz 802.11ac 4×4:4 MU-MIMO and 2.4 GHz 802.11n 4×4:4 MIMO
• 5 GHz: Four spatial stream multi user (MU) MIMO for up to 1733 Mb/s wireless data rate to up to three MU-MIMO capable client devices simultaneously
• 5 GHz: Four spatial stream Single User (SU) MIMO for up to 1,733 Mb/s wireless data rate to individual 4×4 VHT80 or 2×2 VHT160* client devices
• 2.4 GHz: Four spatial stream single user (SU) MIMO for up to 800 Mb/s wireless data rate to individual 4×4 VHT40 client devices (600 Mb/s for HT40 802.11n client devices)
• DFA (dynamic frequency adjustment) optimizes available channels and provides proper transmission power

• Short guard interval for 20 MHz, 40 Mhz, 80 Mhz and 160* Mhz channels
• Transmit beam forming (TxBF) for increased signal reliability and range
• 802.11n/ac packet aggregation: Aggregated Mac Protocol Data Unit (A-MPDU), Aggregated Mac Service Data Unit (A-MSDU)

Interfaces
• 1x 100/1000/2500Base-T autosensing (RJ-45) port, Power over Ethernet (PoE)
• 1x 10/100/1000Base-T autosensing (RJ-45) port, Power over Ethernet (PoE)
• 1x Bluetooth Low Energy (BLE) radio, integrated antenna
  – 9.5 dBm transmit power (typical, basic rate)
  – 92.5 dBm(Typical) receive sensitivity
• 1x USB 2.0 (Type A connector)
• 1x management console port (RJ-45)
• Reset button: Factory reset
• Kensington security slot
• AP1232: 8x RP-SMA Antenna connectors

Antenna
• AP1232: External 44:4 @ 2.4 GHz, dual 4×4:4 @ 5 GHz
  – 8 RP-SMA connectors for external dual band antennas.

Capacity
• Up to 8 SSID per radio (total 24 SSID)
• Support for up to 768 associated client devices per AP

Power
• Maximum (worst case) power consumption:
  – 27.6 W (PoE or DC)
  – Excludes power consumed by external USB device; USB with 500mA load can add up to 2.9 W
  – Maximum power consumption in idle mode: 13.5 W
• Power over Ethernet (PoE):
  – 48 V DC (nominal) 60W/802.3at compliant source; If PoE PSE side does not support LLDP, AP would be powered by 30W/802.3at
  – Unrestricted functionality with 802.3 at High PoE (4-pair)
  – The USB port is disabled and all the three radio will operate in 2×2:2 mode when the AP is powered by 30W 802.3at PoE source

Garansi produk: 1 Tahun
