BLACKMAGIC DESIGN DeckLink Mini Monitor 4K

Deskripsi

Anugrahpratama.com Jual BLACKMAGIC DESIGN DeckLink Mini Monitor 4K

Spesifikasi:

Connections

• SDI Video Input : 1x 10 bit SD/HD/Ultra HD switchable
• SDI Audio Output : 16 channels embedded in SD, HD, Ultra HD
• HDMI Video Output : 1x HDMI 2.0a connector
• HDMI Audio Output : 8 Channels embedded in SD, HD, Ultra HD
• Computer Interface : PCI Express 4 lane generation 2, compatible with 4, 8 and 16 lane PCI Express slots

Supported Codecs

• AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR & DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10-bit 4:2:2

Software

• Software Included : Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac OS and Windows. Media Express, Blackmagic Desktop Video Utility and Blackmagic driver on Linux
• Internal Software Upgrade : Firmware built into software driver. Loaded at system start or via updater software
• Physical Installation : PCI Express 4 lane generation 2, compatible with 4, 8 and 16 lane PCI Express slots on Mac OS, Windows and Linux. Mac OS systems require a Mac Pro computer with PCI Express slots. Please check the Support pages to see the full system requirements

Software Applications

• DaVinci Resolve
• Adobe Premiere Pro CC
• Avid Media Composer
• Adobe Photoshop CC

Video Standards

• SDI Compliance : SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 425M, SMPTE 2081, ITU-R BT.656 and ITU-R BT.601
• SDI Metadata Support : RP 188/SMPTE 12M-2 and closed captioning
• Audio Sampling : Television standard sample rate of 48 kHz and 24 bit
• SDI Color Precision : 8, 10, 12-bit RGB 4:4:4 in all modes up to 1080p60, and 8, 10-bit YUV 4:2:2 in all modes
• SDI Video Sampling : 4:4:4 & 4:2:2
• Color Space : REC 601, REC 709, REC 2020
• SDI HDR Support : HDR static metadata packing, HLG and PQ transfer characteristics
• HDMI Video Sampling : 4:4:4, 4:2:2 & 4:2:0
• HDMI Configuration : HDMI 2.0a supports Deep Color and HDR. Automatically configures to connected display
• HDMI Resolution : Pixel for pixel HD resolution output to connected device
• HDMI Color Precision : Up to 12-bit (Deep Color)
• HDMI HDR Support : HDR static metadata packing, HLG and PQ transfer characteristics
• Multiple Rate Support : HDMI and SDI video connections are switchable between SD/HD/2K and 4K

Operating Systems

• Mac 11.1 Big Sur, Mac 12.0 Monterey or later
• Windows 10 64-bit, Windows 11
• Linux

Power Consumption

• 10 Watts

Garansi produk: 3 Year Limited Manufacturer’s Warranty
